288-864f MicroFlex™ with FlexRibbon® Cable

288-864f MicroFlex™ with FlexRibbon® Cable
Product description

Prysmian’s MicroFlex™ cables deliver enhanced jetting performance for underground microduct installations and for jetting directly over existing cables. The FlexRibbon® technology from Prysmian allows for mass-fusion splicing while keeping the cable's outer diameter small, making it suitable for diameter-sensitive applications. By utilizing 200μm fiber, these cables achieve further reductions in weight and diameter that are not possible with standard 250μm fiber. This compact cable combines high reliability with a reduced size and weight, ensuring optimal blowing performance.

MicroFlex™ cables are an excellent choice for network operators who want to maximize duct utilization, defer capital expenditures to align with revenue streams, maintain flexibility for future growth, and minimize installation and upgrade costs.



Resources



Part Numbers

U.S.: F-RCFMDS1JKT-12-2X- 288-E7, F-RCFMDS1JKT-12-2X- 432-E7, F-RCFMDS1JKT-24-2X- 864-E7

Global: M-RCFMDS1JKT-12-2X- 288-E7, M-RCFMDS1JKT-12-2X- 432-E7, M-RCFMDS1JKT-24-2X- 864-E7



Specifications and Ratings

Applications: Jetted microduct deployment, installed in microducts or partially filled duct Construction Central tube construction containing twelve-fiber flexible ribbons

Fiber Counts: 288, 432, 864

Fiber Types: BBXS200 G.657.A2 Bend-Insensitive SMF

Standards: Tested in accordance with ICEA744 and with relevant EIA/TIA-455 series FOTPs for microduct

Registered Supplier: ISO 9001, ISO 14001, TL 9000, and OHSAS 18001



Features and Benefits

Optimal Jetting Performance

  • Reduced size and weight for installation in microduct
  • Optimized for jetted microduct installations

FlexRibbon Technology

  • FlexRibbon conforms to small, round tubes without stress or damage
  • Fibers can be mass-fusion spliced
  • Each 12- or 24-fiber ribbon is individually numbered with a barcode

Reduced Total Installed Cost

  • Defer CAPEX by maximizing duct utilization
  • Reduced installation and upgrade costs
  • Minimize disruption to underground infrastructure
  • Quick installation, long lengths, and high speeds
  • Allow use of ducts already containing cable

BendBrightXS™ Fiber

  • Exceeds the requirements of ITU G.657.A2
  • Superior micro- and macrobend performance
  • Improved bend performance in both cables and closures
  • An essential component in many of Prysmian's highest-density cables









Product datasheet
